Packaging Made Simple with Automatic Waste Paper Baler and Carton Bale Press Machine

Warranty : 1 Year

Type : Other

Applicable Industries : Energy & Mining

Showroom Location : None

Video outgoing-inspection : Provided

Machinery Test Report : Provided

Warranty of core components : 1 Year

Core Components : Motor

Condition : New

Application : Food, Textiles, waste paper,cardboard,carton,used clothing, Packaging straw

Packaging Type : Cartons, Bags, Belt, Bale

Packaging Material : Plastic, Wood, iron wire

Automatic Grade : Automatic

Driven Type : Hydraulic

Voltage : 380V

Power : 22

Place of Origin : Henan, China

Brand Name : Sinolion

Weight : 35000 KG

Dimension(L*W*H) : 10200*16200*5370

Key Selling Points : Automatic

Product name : horizontal waste paper bale press machine /carton bale press machine

Keyword : carton bale press machine

Name : horizontal baler machine

Key Word : horizontal waste paper bale press machine

Color : as per customized

Capacity : 10-15Tons/h

Sales service : engineer overseas available

Supply Ability : 50 Set/Sets per Month carton recycling machine

Price : $12,500.00 - $40,000.00/sets

MOQ : 1 unit

Contact Now

Low price horizontal waste paper bale press machine /carton bale press machine

Production description

Horizontal hydraulic baling machine is used for packing materials .Such as cotten ,wool,sack,waste paper,crop stalks,rice straw,plastic,cotton,sawdust etc,for easy storage and transportation.Adopting PLC Automatic controller operation system.The system will automaticly ensure the safety of labor and equipment.It is also characteristic of low power consumption ,high output,easy operation etc.





Packaging Made Simple with Automatic Waste Paper Baler and Carton Bale Press Machine

 Packaging Made Simple with Automatic Waste Paper Baler and Carton Bale Press Machine



The baler machine with the door is widely used to press waste plastic bottle.



Packaging Made Simple with Automatic Waste Paper Baler and Carton Bale Press Machine









Main Features

1.The host frame system: More high quality steel gas shielded welding casting solid framework, advanced mechanical design makes equipment durability.
2. Conveying system:High quality thickening flange beam frame, high strength steel plate type transmission belt.
3. Hydraulic System : Hydraulic pump, solenoid valve, key parts adopt imported components and hydraulic cylinder oil seal, packing pressure, fast, durable, low noise.
4.Electric control system: Using Siemens motor, original mitsubishi PLC programming controller.Other buttons, sensors, infrared correlation, such as remote control system for the key parts adopt imported components, key operation simple and convenient maintenance.
5.Security alarm system:Program control five safety automatic lock down alarm. In the equipment misuse, lack of power supply, power phase sequence error, high pressure, people stray into the mouth when the automatic shutdown alarm.



Packaging Made Simple with Automatic Waste Paper Baler and Carton Bale Press Machine



Packaging Made Simple with Automatic Waste Paper Baler and Carton Bale Press Machine



Technicial parameters



Model YYD-100 YYD-120 YYD-160 YYD-200
Main nominal thrust (KN) 1000 1200 1600 2000
Baler Size W*H*L(mm) 900*1000*adjustable 900*1100*adjustable 1100*1300*adjustable 1100*1300*adjustable
Bale density(kg/m3) 400-450 400-450 400-450 400-450
Voltage 3PH380V 3PH380V 3PH380V 3PH380V
Power(KW) 22 22 22+15 22+15
Capacity(Ton/hour) 2-5(3-5bag) 5-8(5-10bag) 8-12(8-10bag) 10-15(10-12bag)
Bale line 5 5 5 5
Feed opening sizeL*W(mm) 1500*820 1685*860 1880*1060 1960*1145
Weight(KG) 18000 23000 25000 35000
Machine size  8660*12000*4120  8700*12200*4120  8700*12200*4120  10200*16200*5370
Automatic Grade Semi-automatic Semi-automatic Semi-automatic Semi-automatic



Packaging & Shipping

Packaging Made Simple with Automatic Waste Paper Baler and Carton Bale Press MachinePackaging Made Simple with Automatic Waste Paper Baler and Carton Bale Press Machine


Case

Packaging Made Simple with Automatic Waste Paper Baler and Carton Bale Press MachinePackaging Made Simple with Automatic Waste Paper Baler and Carton Bale Press Machine



Company Information

Packaging Made Simple with Automatic Waste Paper Baler and Carton Bale Press Machine

Packaging Made Simple with Automatic Waste Paper Baler and Carton Bale Press Machine

Packaging Made Simple with Automatic Waste Paper Baler and Carton Bale Press Machine

FAQ

 1. Payment accepted: After confirming all the details with our sales, we will make contract for you to make deposit first and the balance need to be cleared against shipping. Generally we accept most of the payment methods like TT, L/C, PayPal, West union, Moneygram.
2. Lead time: 7 working days against your deposit.
3. What about the quality: We use the best national certified steel and top brand e-parts
4. Warranty: 12 months warranty and life time service.
5. Certificate: ISO, CE, CCC
6. How can I get to your company: We are located in zhengzhou City. You can fly to XINZHENG INTERNATIONAL AIRPORT and we will pick you up there.
